保偏光纤 熊猫光纤

  • 保偏光纤 熊猫光纤
  • 保偏光纤 熊猫光纤
  • 保偏光纤 熊猫光纤
  • 保偏光纤 熊猫光纤
型号︰PM fiber
品牌︰3V-TECH
原产地︰中国
单价︰CNY ¥ 1 / 米
最少订量︰100 米

 共有 22 相关信息
上一个1819202122下一个

产品描述

Polarization Maintaining fiber for component

Grinding Polarization Maintainling fiber for component



Characteristics:

Excellent grinding properties

Tight geometric tolerances

High Invironmental stability and reliability



Applications:

High performance transmission laser pigtails

Polarization sensitive components

Polarization maintaining device pigtails





Polarization Maintaining fiber for fibre coil

Characteristics:

Short beat length

Extremely high birefringence

excellent polarization maintaining properties

Tight geometric tolerance and very low attenuation

Low bending-induced attenuation

Tight tolerance,dual layer,and UV-acrylate coating

High Invironmental stability and reliability





Applications:

Fibre optic gyroscopes(FOGs)

Polarization maintaining fused-fibre couplers

Polarization sensitive components

High performance transmission laser pgtails

Polarization-based sensors



Technical parameters

Features Unit Product indicator
Product type / PM13G-60-U10 PM13G-80-U13
PM13G-80-U16
PM13G-125-U25 PM15G-60-U10 PM15G-80-U13
PM15G-80-U16
PM15G-125-U25
Optical properties
Working wavelength nm 1310 1310 1310 1550 1550 1550
Cutoff wavelength nm 1100~1290 1100~1290 1100~1290 1290~1520 1290~1520 1290~1520
Mode field diameter μm 6.0±0.5 6.0±0.5 6.0±0.5 6.0±0.5 6.0±0.5 6.0±0.5
Attenuation dB/km ≤ 0.6 ≤ 0.6 ≤ 0.6 ≤ 0.5 ≤ 0.5 ≤ 0.5
Beat length mm ≤2.5 ≤2.5 ≤2.5 ≤3.0 ≤3.0 ≤3.0
Typical crosstalk dB/km ≤-23 ≤-30 ≤-30 ≤-30 ≤-30 ≤-30
Geometric properties
Cladding layer diameter μm 60.0±1.0 80.0±1.0 125.0±1.0 60.0±1.0 80.0±1.0 125.0±1.0
Coating type / Double-layer UV-curable acrylic resin
Coating diameter μm 105.0±2.0 135.0±1.0
168.0±1.0
245.0±2.0 105.0±2.0 135.0±1.0
168.0±1.0
245.0±2.0
Core-cladding concentricity μm ≤1.0 ≤1.0 ≤1.0 ≤0.5 ≤0.5 ≤0.5
Cladding out-of-roundness / ≤1.0% ≤1.0% ≤1.0% ≤1.0% ≤1.0% ≤1.0%
Environmental and mechanical properties
Operating temperature ºC -50~+105 -50~+105 -50~+105 -50~+105 -50~+105 -50~+105
Screening tension kpsi 100 100 100 100 100 100
付款方式︰TT
